All photos are for representation purposes only and may not be a photo of the exact product being purchased
MS7503A2030: Zelix S03 Series Spring Return Direct Coupled Actuator
Description
HYR Zelix S03 Series Spring Return Direct Coupled Actuator, 24 Vac/Dc, 27 Lb-In Torque, 0/2-10Vdc, 4-20 Ma with 500 Ohm Resistor, On/Off, SPDT Floating Control Signal, 2-10Vdc Feedback, 90 Second Nominal Driving Time, 25 Second Maximum Spring Return
Additional Product Details
24 Vac/Dc, 27 Lb-In Torque, 0/2-10Vdc, 4-20 Ma with 500 Ohm Resistor, On/Off, SPDT Floating Control Signal, 2-10Vdc Feedback, 90 Second Nominal Driving Time, 25 Second Maximum Spring Return
Downloads
MS7503A2030-Submittal.pdf
MS7503A2030-Install.pdf
